Custom Connector Seal
Custom Connector Seal Development for Automotive OEM Applications
Key Features
| Material | VMQ Silicone / HCR Silicone / Liquid Silicone Rubber (LSR) |
| Function | Waterproof sealing for Automotive connector and Wiring Harness |
| Operating Temperature | -55°C to +200°C (Continuous) |
| Hardness | 50 ± 5 Shore A (Multiple options available) |
| IP Rating | IP67 / IP68 |
| Standard Color | Red (Custom colors available) |
Product Overview
ARPL is a leading custom connector seal manufacturer providing custom connector seal development for automotive OEM applications. We develop custom connector seals from customer drawings or samples, offering a complete range of materials, pole configurations, and sizes to meet your specific wiring harness requirements. Our custom connector seal development process ensures IP67 IP68 waterproof protection for demanding automotive environments.
As an IATF 16949 certified custom connector seal manufacturer, we provide full PPAP documentation support for automotive programs. Our in-house tooling capability enables faster development cycles for custom connector seal projects, with typical lead times of 4-8 weeks from drawing approval to first samples.
Why Choose ARPL for Custom Connector Seals?
- ISO 9001 & IATF 16949 certified custom connector seal manufacturer
- 30+ years expertise in custom rubber seal development
- In-house tooling, compounding, and cryogenic deflashing capabilities
- Full PPAP documentation for automotive OEM applications
- Custom connector seal supplier exporting to 20+ countries
Custom Connector Seal Manufacturer – OEM Connector Seal Development
ARPL is a leading custom connector seal manufacturer providing custom connector seal development for automotive OEM and Tier-1 wiring harness manufacturers. As an automotive connector seal supplier in India, we develop custom connector seals from customer drawings or samples with full engineering support. Our custom connector seal development process ensures precision manufacturing with IP67 IP68 waterproof protection.
We manufacture custom connector seals in configurations from 2-pin to 36+ pin to match any connector housing requirement. Our custom connector seal manufacturer capabilities include compression moulding, transfer moulding, and injection moulding for high-volume production requirements.
Material Options for Custom Connector Seals
ARPL offers a complete range of materials for custom connector seal development to match your application requirements.
- VMQ Silicone Custom Connector Seal: High temperature -55°C to +200°C, UV/ozone resistant
- HCR Silicone Custom Connector Seal: High Consistency Rubber for compression/transfer moulding
- LSR Custom Connector Seal: Liquid Silicone Rubber for injection moulding, high-volume production
- NBR Custom Connector Seal: Oil and fuel resistant -40°C to +120°C for engine bay applications
- EPDM Custom Connector Seal: Weather and ozone resistant for exterior applications
- HNBR Custom Connector Seal: Combined oil resistance and higher temperature capability
- FKM Custom Connector Seal: Extreme chemical and temperature resistance
All custom connector seal materials are RoHS and REACH compliant for automotive applications.
Custom Connector Seal Development Process
Our custom connector seal development process includes design review, tooling development, first article inspection, and full PPAP documentation. We provide control plans, FMEA, capability studies, and material certifications for automotive OEM applications.
Related Sealing Products
Explore our complete range of connector seals, rubber grommets for wiring protection, rubber O-rings and sealing rings, and rubber gaskets and sealing solutions.
Industry Applications for Custom Connector Seals
ARPL's custom connector seal development serves a wide range of automotive and industrial applications. Our custom connector seal manufacturer capabilities enable us to develop seals for any connector housing requirement with IP67 IP68 waterproof protection. Contact us for custom connector seal development for your specific application.
Sensor Connectors
Connectors
Connectors
Connectors
Connectors
Connectors
Connectors
HEV/PHEV Connectors
Vehicle Segment Applications
ARPL supplies silicone connector seals to OEMs and Tier-1 wiring harness manufacturers serving diverse vehicle segments with high-temperature requirements:
- Passenger Cars: Exhaust sensors, turbocharger connectors, and underhood high-temperature applications
- Commercial Vehicles: DPF/SCR sensor connectors, exhaust aftertreatment system connectors for trucks and buses
- Electric Vehicles (EV): Battery management system (BMS), motor controller, inverter, and DC fast charging connectors
- Hybrid Electric Vehicles (HEV/PHEV): High-voltage connectors, regenerative braking sensors, and thermal management systems
- Motorcycles: Exhaust sensor connectors, exposed wiring harness applications requiring UV resistance
- Off-Highway Vehicles: Construction and agricultural equipment with high-temperature engine and exhaust applications
High-Temperature Operating Environments
Silicone connector seals excel in environments where extreme temperatures are encountered:
- Exhaust Gas Temperature (EGT) Sensors: Operating at +200°C continuous near exhaust manifold and turbocharger
- Turbocharger Actuator Connectors: Exposed to radiant heat from turbo housing (150°C to 200°C)
- EGR Valve & Cooler Connectors: High exhaust gas temperatures in emissions control systems
- Diesel Particulate Filter (DPF) Sensors: Temperature and pressure sensors in exhaust aftertreatment
- SCR System Connectors: AdBlue/DEF dosing unit and NOx sensor connectors
- Lambda/Oxygen Sensors: Pre-cat and post-cat O2 sensor connectors near exhaust
- EV Motor Controllers: High-voltage connectors in thermally demanding motor and inverter applications
- Exterior Connectors: UV-exposed lighting, antenna, and sensor connectors requiring weathering resistance
OEM Connector System Compatibility
ARPL develops silicone connector cavity seals compatible with major automotive connector systems used globally by OEMs and Tier-1 suppliers:
- Compatible with standard 2-way female connector housings from leading connector manufacturers
- Custom development available for proprietary OEM connector designs
- Supports single-wire and multi-wire sealing configurations
- Available in multiple wire gauge accommodations (0.5mm² to 2.5mm² typical)
- Designed to meet automotive connector sealing standards including USCAR, LV214, and OEM-specific requirements
Industry Standards & Compliance
Our silicone connector seals are manufactured to meet stringent automotive industry requirements:
- IP67/IP68 Protection: Dust-tight and water immersion resistant when properly installed
- Temperature Range: -55°C to +200°C continuous operation
- Material Compliance: RoHS compliant, REACH compliant, ELV compliant
- Quality Certification: Manufactured under ISO 9001:2015 and IATF 16949:2016 quality management systems
- Automotive Testing: Tested per OEM specifications for compression set, thermal aging, and weathering
- PPAP Support: Full Production Part Approval Process documentation available
Why Choose Silicone Material for Connector Seals?
Silicone Rubber (VMQ) is the preferred elastomer for high-temperature automotive connector seals due to its unique combination of properties:
- Extreme Temperature Range: Operates from -55°C to +200°C continuous, with intermittent capability to +230°C
- UV and Ozone Resistance: Excellent weathering resistance for exterior and exposed applications
- Low Compression Set: Maintains sealing force over extended periods even under thermal cycling
- Excellent Low-Temperature Flexibility: Remains flexible in extreme cold where other materials become brittle
- Electrical Insulation: Good dielectric properties for high-voltage EV applications
- Long Service Life: Resistant to aging, oxidation, and degradation over time
Looking for a different material? ARPL also manufactures connector seals in NBR for oil-resistant applications (-40°C to +120°C), EPDM for weather sealing, HNBR for combined oil resistance and higher temperature, and FKM (Viton) for extreme chemical and temperature resistance. Contact our engineering team for material selection assistance.
Need Custom Sealing Solutions?
Our engineering team can develop tailored solutions for your specific requirements. From material selection to custom designs, we're here to help.
Frequently Asked Questions
Find answers to common questions about custom connector seal development and OEM connector seal manufacturing
A custom connector seal is a precision-moulded rubber seal developed to customer specifications for automotive wiring harness applications. ARPL develops custom connector seals from customer drawings or samples with various pole configurations, materials, and sizes.
ARPL offers custom connector seals in VMQ silicone (-55°C to +200°C), HCR silicone, LSR, NBR for oil resistance (-40°C to +120°C), EPDM for weather resistance, HNBR for combined oil and temperature resistance, and FKM (Viton) for extreme chemical resistance.
ARPL manufactures custom connector seals in configurations from 2-pin to 36+ pin. We can develop any pole configuration to match customer connector housing requirements with full PPAP documentation.
Yes, ARPL is an IATF 16949 certified custom connector seal manufacturer providing full PPAP documentation including control plans, FMEA, capability studies, and material certifications for automotive OEM applications.
Custom connector seal development typically takes 4-8 weeks from drawing approval to first samples, depending on complexity. ARPL's in-house tooling capabilities enable faster development cycles.
Yes, ARPL is an ISO 9001 and IATF 16949 certified custom connector seal manufacturer exporting to OEMs and Tier-1 wiring harness manufacturers in Germany, USA, Mexico, Turkey, Brazil, UK, UAE, Thailand, Vietnam and other automotive hubs.
